SI series pneumatic standard cylinder

SI standard cylinder‌ is a cylinder that complies with ISO15552 (formerly ISO6431) standards and has the following main characteristics and technical parameters:

‌Structural features‌:

‌Rodless design‌: SI standard cylinders have no rods, and the cylinder barrel adopts an aluminum tube M-shaped design with good corrosion resistance‌.

‌Piston seal‌: It adopts two Y-type single-item structures with compensation function, long life and low starting pressure‌.

‌Shaft seal material‌: PU material is selected, with high strength, high toughness, wear resistance, oil resistance, aging resistance and other characteristics‌.

‌Piston rod material‌: 45# steel surface hard chrome-plated grinding rod, roughness Ra<0.4, with good wear resistance and rust resistance‌3.

‌Technical parameters‌:

‌Action type‌: double action‌.

‌Use pressure range‌: 0.1~0.9MPa‌.

‌Guaranteed pressure resistance‌: 1.35MPa‌.

‌Use temperature range‌: -5~70℃‌. ‌ Speed range: 50~800mm/s. ‌ Buffer type: adjustable buffer. ‌ Buffer stroke: 24, 32. ‌ Pipe diameter: G1/8", G1/4", G3/8", G1/2", G3/4". ‌ Installation accessories and specifications: ‌ Inner diameter specifications: 32, 40, 50, 63, 80, 100, 125, 160, 200. ‌ Fixed type: basic type FA, FB, CA, CB, SDB, LB, TC.
