Specifications
Cylinder diameter: 20mm, 25mm, 32mm, 40mm
Stroke: 25mm, 50mm, 75mm, 100mm, 125mm, 150mm, 200mm, 250mm, 300mm, 360mm, 450mm, 500mm, 550mm, 600mm, 750mm, 1000mm12
Mounting form: basic type (with bosses on both sides)
Action mode: double acting
Using flow: air
Guaranteed pressure resistance: 1.5MPa
Maximum working pressure: 1.0MPa
Minimum working pressure: 0.05MPa
Environmental and fluid temperature: -10 to 70 degrees (not frozen) without magnetic switch; -10 to 60 degrees (not frozen) with magnetic switch
